Two-wheeled vehicle
The electric bicycle battery utilizes AGM separators of moderate thickness, which are firmly bonded to the electrode plates to prevent the shedding of active material. This design effectively mitigates concentration polarization, thereby extending the battery's discharge duration and enhancing the vehicle's overall cruising range.
This type of battery features a fully sealed, leak-proof structural design that guarantees zero leakage. With the exception of an inverted orientation, the battery can be installed in any position while effectively maintaining its rated capacity.
This electric bicycle battery incorporates improved conductive materials, which serve to reduce water loss caused by high voltage during the charging process and lower internal resistance. Furthermore, it maintains stable, undiminished capacity in low-temperature environments, boosting the winter cruising range by up to 20%. Moreover, the battery's overall capacity has been increased by 5%, further extending the vehicle's travel distance.
*The table is horizontally scrollable.
| Model | Dimensions(mm) | Current / Power | Technical Details / Specifications |
|---|---|---|---|
| 60V/100A | 555*390*230 | 100A/3600W | Rated Voltage: 64V, Rated Capacity: 105Ah/6720Wh, Charging Voltage / Max Charging Current: 73V/20A, 最大放电电流: 100A, Weight (Horizontal)(49.3KG) |
| 48V/105A Square Type / Square Version |
440*340*225 | 100A/3000W | Rated Voltage: 51.2V, Rated Capacity: 105Ah/5120Wh, Charging Voltage / Max Charging Current: 58.2V/20A, 最大放电电流: 100A, Weight (Horizontal)(44.8KG) |
| 60V/105A Square Type / Square Version |
440*410*225 | 100A/3600W | Rated Voltage: 64V, Rated Capacity: 105Ah/6720Wh, Charging Voltage / Max Charging Current: 73V/20A, Max Discharging Current: 100A, Weight (Horizontal)(54.8KG) |
| 72V/105A Square Type / Square Version |
470*440*225 | 100A/4000W | Rated Voltage: 76.8V, Rated Capacity: 105Ah/8063Wh, Charging Voltage / Max Charging Current: 87.6V/20A, Max Discharging Current: 100A, Weight (Horizontal)(65.0KG) |
| 48V/22A | 145*160*235 | 50A/800W | Rated Voltage: 51.2V, Rated Capacity: 22Ah/1126.4Wh, Charging Voltage / Max Charging Current: 58.4V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG) |
| 60V/22A | 145*160*280 | 50A/1000W | Rated Voltage: 64V, Rated Capacity: 22Ah/1408Wh, Charging Voltage / Max Charging Current: 73V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG) |
| 72V/22A | 145*160*335 | 50A/1200W | Rated Voltage: 76.8V, Rated Capacity: 22Ah/1689.6Wh, Charging Voltage / Max Charging Current: 87.6V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG) |
