Tricycle

The battery for this electric tricycle features a high-strength AGM separator structure that is tightly bonded to the electrode plates; this design effectively minimizes the shedding of active materials while enhancing the battery's cycle stability and sustained discharge capability. Through an optimized internal structural design, the battery effectively reduces concentration polarization and boosts power output performance, thereby improving the vehicle's overall cruising range and operational efficiency.

This battery utilizes a fully sealed, maintenance-free design, offering excellent leak-proof properties that ensure both safety and reliability. With the exception of an inverted orientation, the battery can be flexibly installed at various angles to accommodate diverse vehicle structures, all while maintaining a stable capacity output to meet the specific operational requirements of different types of electric tricycles.

Furthermore, the battery incorporates upgraded high-conductivity materials and a low-internal-resistance manufacturing process. This effectively minimizes energy loss during charging and discharging cycles and reduces water loss rates, even in high-temperature or high-voltage environments. Even under low-temperature conditions, the battery maintains stable discharge performance, significantly improving the vehicle's cruising range during the winter season. The overall capacity has been further optimized and upgraded to provide the vehicle with an extended cruising range and more enduring power support, making it widely applicable across a variety of electric tricycle use scenarios—including cargo transport, passenger services, and daily commuting.

Contact Us

Tricycle
Tricycle
Tricycle

*The table is horizontally scrollable.

Model Dimensions(mm) Current / Power Technical Details / Specifications
60V/100A 555*390*230 100A/3600W Rated Voltage: 64V, Rated Capacity: 105Ah/6720Wh, Charging Voltage / Max Charging Current: 73V/20A, Max Discharging Current: 100A, Weight (Horizontal)(49.3KG)
48V/105A
Square Type / Square Version
440*340*225 100A/3000W Rated Voltage: 51.2V, Rated Capacity: 105Ah/5120Wh, Charging Voltage / Max Charging Current: 58.2V/20A, Max Discharging Current: 100A, Weight (Horizontal)(44.8KG)
60V/105A
Square Type / Square Version
440*410*225 100A/3600W Rated Voltage: 64V, Rated Capacity: 105Ah/6720Wh, Charging Voltage / Max Charging Current: 73V/20A, Max Discharging Current: 100A, Weight (Horizontal)(54.8KG)
72V/105A
Square Type / Square Version
470*440*225 100A/4000W Rated Voltage: 76.8V, Rated Capacity: 105Ah/8063Wh, Charging Voltage / Max Charging Current: 87.6V/20A, Max Discharging Current: 100A, Weight (Horizontal)(65.0KG)
48V/22A 145*160*235 50A/800W Rated Voltage: 51.2V, Rated Capacity: 22Ah/1126.4Wh, Charging Voltage / Max Charging Current: 58.4V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG)
60V/22A 145*160*280 50A/1000W Rated Voltage: 64V, Rated Capacity: 22Ah/1408Wh, Charging Voltage / Max Charging Current: 73V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG)
72V/22A 145*160*335 50A/1200W Rated Voltage: 76.8V, Rated Capacity: 22Ah/1689.6Wh, Charging Voltage / Max Charging Current: 87.6V/8A, Max Discharging Current: 50A, Weight (Vertical)(? KG)
