Lithium Battery Pack (Lithium Iron Phosphate)
Lithium Battery Packs (Lithium Iron Phosphate)
6.4V 6.3 Ah | 12.8V 6.3 / 12 / 15 / 54 Ah
■ Cycle Life: >2000 Cycles
■ Equipped with BMS Protection
■ Rechargeable Lithium Batteries (Supports OEM/ODM Customization)
*The table is horizontally scrollable.
| Model | LFP-6.4-6.3-40 | LFP-12.8-6.3-80 | LFP-12.8-12-150 | LFP-12.8-15-190 | LFP-12.8-54-700 |
|---|---|---|---|---|---|
| Rated Voltage(V) | 6.4 | 12.8 | 12.8 | 12.8 | 12.8 |
| Rated Current(A) | 6.3 | 6.3 | 12 | 15 | 54 |
| Rated Capacity(Wh) | 40.32 | 80.64 | 153.6 | 192 | 691.2 |
| Cell type | LiFePO4 32700 | LiFePO4 32700 | LiFePO4 32700 | LiFePO4 33140 | LiFePO4 33140 |
| Maximum charging voltage | 7.3 | 14.6 | 14.6 | 14.6 | 14.6 |
| Minimum discharge voltage | 5 | 10 | 10 | 10 | 10 |
| Standard charging current | 3 | 3 | 6 | 7.5 | 27 |
| Standard discharge current | 6 | 6 | 12 | 15 | 54 |
| Cycle life | >2000(80% DOD @0.2C) | ||||
| Working temperature | Charging 0℃-45℃, Discharging -10℃-55℃ | ||||
| Storage temperature | -20℃-50℃ | ||||
| Warranty | 3 Years | ||||
